Icecrypt STC3250CCIHD Digital Receiver High Definition Satellite and Terrestrial ReceiverCard Reader and CI SlotRF Modulator
Full HD (1080P) Satellite and Ground (Combination) DVB-S2/DVB-S/DVB-T2/DVB-T/H.264/MPEG4 HD RECEIVER
COMPOSITE, RF MODULATOR, HDMI, SCART, AND # ANTENNA IN LIN MAX 12,18 ✰ Page: “Internet Connection Required/3rd Party Apps subject to change 1 S/PDIF
CI SLOT, DUAL USB ETHERNET PORT, WIFI SUPPORT, CONAX CARD READER (DONGLE SUPPLIED SEPARATELY),
MEDIA SUPPORT, TIME SHIFT, RECORDING, AND PLAYBACK WITH AN EXTERNAL HDD (USB 2.0)
FUNCTIONS FOR YOUTUBE, RSS READER, AND WEATHER
FEATURES
- Embedded Conax Card Reader
- Single Common Interface Slot
- Vacuum Fluorescent Display
- Up to 6,000 Channels Supported (TV & Radio)
- Two High-Speed USB Ports (Front and Rear)
- Teletext/Subtitles Supported
- True Colour, User Friendly On Screen Display (OSD)
- Timer Support-Set up to Eight Timers
- Multiple Sort Types – including FAV, SAT, HD
- YouTube, RSS Reader, and Weather Forecast
- Full 1080P High Definition by HDMI**
- Supports MPEG4/MPEG2-HD/SD
- DVB-S2/DVB-S/DVB-T2/DVB-T
- Record, Timeshift, and Playback with External HDD
- EPG Support (Where Broadcast)
- Parental Lock
- Embedded Games Digital Audio Output-Coaxial and Optical
- Internet Connection Required/3rd Party Apps subject to change
- HDMI Lead Not included RF IN RF OUT 012V Se + 90% ….. R$ 232
- Ethernet Connection and WiFi Support (Icecrypt Wifi Dongle Available separately)
- DiSEqC 1.0, 1.1, 1.2, and USALS Compatible
- Channel Switching Time <1 Second
- SD Output by SCART or RCA
- Multi-Language Support
- 0.5W Stand-by Power Consumption
- VIDEO OUT SRDIE AUDIO 100-240V 50 Power Consumption Operation mode 20 POWER A
ICECRYPT STC3250CCIHD satellite receiver with CI & HD RF modulator, FullHD 1080P, USB | JK Dish Info
dumpfile ICECRYPT STC3250CCIHD
Specifications
SATELLITE TUNER & CHANNEL DECODER
- Input Connector:- FEC Decoder F-type, IEC 169-24, Female
- Output Connector: – F-type, IEC 169-24, Female
- Frequency Range :-950MHz ~ 2150MHz
- Input Impedance :- 75Ω, unbalanced
- Sensitivity : – 65 to -25dBm
- LNB Power :-13.5/18VDC, max.500mA
- 22KHz Tone : (22±4)KHz, (0.6±0.2)V
- DiSEqC Control:-V1.0/1.1/1.2/USALS Compatible
- Demodulation :- QPSK / 8PSK
- Input Symbol Rate :- 1 ~ 45 Ms/s
- FEC Decoder :- 1/2, 2/3, 3/4, 5/6 and 7/8 (DVB-S)
- 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9 and 9/10 (DVB-S2)
TERRESTRIAL TUNER & CHANNEL DECODER
- Input Connector IEC Type, Female
- Output Connector IEC Type, Male
- Frequency Range VHF H: 149.5 – 426MHz
- UHF: 434 – 858MHz
- Constellation QPSK/16QAM/64QAM/256QAM
- FEC Decoder 1/2, 2/3, 3/4, 5/6 and 7/8
- Guard Interval 1/4, 1/8, 1/16, 1/32, 19/256, 19/128 and 1/128
- FFT Mode 1K, 2K, 4K, 8K, 16K and 32K
- Channel Bandwidth 7/8MHz
MPEG TRANSPORT STREAM A/V DECODING
- Transport Stream H.264(MPEG-4 part 10, MPEG- 4/AVC and H26L)
- MPEG-II ISO/IEC 13818-2/11172-2
- Profile Level MPEG-4/AVC MP@L4, MPEG-II MP@HL
- Input Rate Max. 120Mbit/s
- Video Formats 4:3 Letter Box, 4:3 PanScan, 16:9
- Video Resolution 720 x 576i, 720 x 576p, 720 x 480i, 720 x 480p
- 1280 x 720p, 1920 x 1080i, 1920 x 1080p
- Audio Decoding Dolby Digital, MPEG-1 Layer 1 and 2, MPEG-2 Layer 2
- Audio Mode Left/Right/Stereo/Mono
- Sampling Rate 32KHz, 44.1KHz and 48KHz (According to input)
MAIN SYSTEM
Main Processor ALI3606C
Memory DDR SDRAM: 1024 Mbits
FLASH: 64Mbits
AUDIO / VIDEO & DATA IN/OUT
RCA CVBS Video Output, Audio L, R Output
Audio Digital Coaxial and Optical
SCART TV SCART (CVBS/RGB)
HDMI Video & Audio Output
USB USB 2.0 Host-Front & Rear Support. (5 Vdc 500 mA max.)
Ethernet RJ45 connector, 100 Mbps
RF In IEC 169-2 Female
RF Out (Modulator) IEC 169-2 Male
RS-232C 9 pin D-SUB (Male) type, Transfer rate 115Kbps
FRONT PANEL
Slot 1 Smart Card Slot
Common Interface 1 CI Slot
Display Vacuum Fluorescent Display (VFD)
Buttons 7 Keys (Power, Left, Right, Up, Down, OK, Menu)
POWER SUPPLY
Input Voltage AC 100-240v, 50/60Hz
Type SMPS
Power Consumption Max. 20W
Standby Power Max. 0.5W
PHYSICAL SPECIFICATION
Size (W x H x D) 260mm X 54mm X 188mm
Weight (Net) 1.2KG
Operating Temp. 0°C ~ +45°C
Storage Temp. -10°C ~ +70°C
FAQ:-
- How to installation channels in this box?
ANS:- Go to the menu and Installation Satellite scan to add channels
